Vibration Reduction Products

OVD

Oil-type Viscosity Damper
Product Application
  • Ensures dynamic stability of equipment when installed with a pneumatic mount system
  • Reduces tack time for production inspection equipment that induces dynamic load
  • Equipment and sites requiring ultra-precision micro-vibration control, such as in semiconductor, LCD, and OLED industries
  • Various inspection equipment, laser-related devices, 3D measuring instruments, and other precision measurement equipment
Product Features
  • Suppresses displacement caused by shock vibrations when combined with a pneumatic mount
  • Ensures consistent damping performance with the same damping force during tension and compression
  • Minimal fluctuation in the natural frequency of the pneumatic mount due to damping force
  • Capable of controlling displacement on both vertical and horizontal axes at standard levels
  • Ensures damping force performance even at small displacements, addressing the drawback of conventional dampers

Product Specifications

Model External Dimensions L×W×H (mm) Mounting Distance Upper (mm) Mounting Distance Lower (mm) Assembly Section Product Weight (kg)
OVD-G
290×216×185
□-185×125
□-125×125
Ø15
17
OVD-S
210×150×190
□-185×125
□-185×125
Ø14
12
Custom manufacturing is available according to customer specifications beyond standard specifications, and specifications are subject to change due to performance improvements.

Product Performance Graph

Impact Vibration Dissipation Force
